- Screen: 6.78" AMOLED - 1264 x 2780
- SoC: Qualcomm Snapdragon 8 Gen 3
- Camera: 3 (50 MP + 8 MP + 2 MP)
- Battery: 6100 mAh
- OS: Android 15
- Weight: 212 grams (7.48 oz)
Select the amount of RAM to evaluate performance more precisely
Scores marked with a red asterisk (*) are approximate, as we currently do not have sufficient test results to make a precise estimation.
Compare OnePlus Ace 3 Pro with other phones
Full specifications
Detailed specifications, tests, and benchmarks of the OnePlus Ace 3 Pro
| Type |
AMOLED |
| Size |
6.78 inches |
| Resolution |
1264 x 2780 pixels |
| Aspect ratio |
19.8:9 |
| PPI |
450 ppi |
| Refresh rate |
120 Hz |
| Adaptive refresh rate |
Yes (1-120 Hz) |
| Max rated brightness |
4500 nits |
| HDR support |
Yes, Dolby Vision |
| Touch sampling rate |
240 Hz |
| Screen protection |
Gorilla Glass Victus 2 |
| Screen-to-body ratio |
91% |
| Display features |
- DCI-P3
- Always-On Display
- DC Dimming |
| Height |
163.3 mm (6.43 inches) |
| Width |
75.27 mm (2.96 inches) |
| Thickness |
8.85 mm (0.35 inches) |
| Weight |
212 g (7.48 oz) |
| Waterproof |
IP65 |
| Advanced cooling |
Vapor chamber |
| Rear material |
Glass |
| Frame material |
Metal |
| Colors |
White, Gray, Green |
| Fingerprint scanner |
Yes, in-display |
Performance
Chipset specifications of the OnePlus Ace 3 Pro
SoC
| Chipset |
Qualcomm Snapdragon 8 Gen 3 |
| Max clock |
3300 MHz |
| CPU cores |
8 (1 + 3 + 2 + 2) |
| Architecture |
- 2 cores at 2.27 GHz: Cortex-A520
- 2 cores at 2.96 GHz: Cortex-A720
- 3 cores at 3.15 GHz: Cortex-A720
- 1 core at 3.3 GHz: Cortex-X4 |
| L3 cache |
12 MB |
| Manufacturing |
TSMC |
| Lithography process |
4 nanometers |
| Neural processor (NPU) |
Hexagon |
GPU
| Graphics |
Adreno 750 |
| GPU shading units |
1536 |
| GPU clock |
903-1000 MHz |
| FLOPS |
~2774 GFLOPS |
Benchmarks
Benchmark results of the OnePlus Ace 3 Pro
Geekbench 6 (Single-Core)
2222
Geekbench 6 (Multi-Core)
6859
Compute Score (GPU)
15243
| Compute Score (GPU) |
15243 |
| Single-core score |
2222 |
| Multi-core score |
6859 |
AnTuTu Benchmark 11
2287429
| CPU |
702174 |
| GPU |
780004 |
| Memory |
352261 |
| UX |
452990 |
| Total score |
2287429 |
3DMark Steel Nomad Light
1650
| Stability |
72% |
| Graphics test |
12 FPS |
| Graphics score |
1650 |
| Graphics test |
31 FPS |
| Section 1 |
35 FPS |
| Section 2 |
31 FPS |
| Section 3 |
26 FPS |
| Graphics score |
8169 |
3DMark Wild Life Extreme
4526
| Stability |
79% |
| Graphics test |
27 FPS |
| Graphics score |
4526 |
| Web score |
13236 |
| Video editing |
6334 |
| Photo editing |
28434 |
| Data manipulation |
12500 |
| Writing score |
17255 |
Recent User Tests
The latest benchmark tests that have been submitted by users
RAM
| RAM size |
12 GB |
| Memory type |
LPDDR5X |
| Memory clock |
4200 MHz |
| Channels |
4 |
Storage
| Storage size |
256 GB |
| Storage type |
UFS 4.0 |
| Memory card |
No |
| Operating system |
Android 14 (Can be upgraded to Android 15) |
| ROM |
ColorOS 15 |
| OS updates |
2 years |
| Security updates |
3 years |
| Capacity |
6100 mAh |
| Max charge power |
100 W |
| Battery type |
Silicon-Carbon (Si/C) |
| Replaceable |
No |
| Wireless charging |
No |
| Reverse charging |
No |
| Fast charging |
Yes (52% in 16 min) |
| Full charging time |
0:38 hr |
| Matrix |
50 megapixels |
| Image resolution |
8192 x 6144 |
| Zoom |
Digital |
| Flash |
Dual LED |
| Stabilization |
Optical |
| 8K video recording |
No |
| 4K video recording |
Up to 60FPS |
| 1080p video recording |
Up to 60FPS |
| Slow motion |
480 FPS (720p) |
| Angle of widest lens |
112Β° |
| Lenses |
1) Standard: 50 MP
2) Ultrawide: 8 MP
3) Macro: 2 MP
|
| Camera features |
- Bokeh mode
- Pro mode |
Standard lens
| Image resolution |
50 MP |
| Aperture |
f/1.8 |
| Focal length |
24 mm |
| Sensor |
Sony IMX890 |
| Sensor size |
1/1.56" (β 0.64 inch) |
| Pixel size |
1 micron |
| Autofocus |
Phase autofocus |
| Stabilization |
Optical |
Ultra-wide lens
| Image resolution |
8 MP |
| Aperture |
f/2.2 |
| Focal length |
16 mm |
| Sensor |
Sony IMX355 |
| Sensor size |
1/4.0" (β 0.25 inch) |
| Pixel size |
1.12 micron |
| Stabilization |
Digital |
Macro lens
| Image resolution |
2 MP |
| Aperture |
f/2.4 |
| Focal length |
22 mm |
| Sensor |
OmniVision OV02B |
| Sensor size |
1/5" (β 0.2 inch) |
| Pixel size |
1.75 micron |
| Stabilization |
Digital |
| Megapixels |
16 megapixels |
| Image resolution |
4608 x 3456 |
| Aperture |
f/2.4 |
| Focal length |
26 mm |
| Sensor |
Samsung ISOCELL S5K3P9 |
| Sensor size |
1/3" (β 0.33 inch) |
| Pixel size |
1 micron |
| Autofocus |
No |
| Stabilization |
Digital |
| Video resolution |
1080p (Full HD) at 30 FPS |
| Depth sensor (TOF 3D) |
No |
| Wi-Fi standard |
Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be) |
| Wi-Fi features |
- Dual Band
- Wi-Fi MiMO
- Wi-Fi Direct
- Wi-Fi Hotspot
- Wi-Fi Display |
| Bluetooth version |
5.4 |
| Bluetooth features |
LE |
| USB type |
USB Type-C |
| USB version |
2 |
| USB features |
- Charging
- USB-Storage mode
- OTG |
| DisplayPort |
No |
| GPS |
GPS, GLONASS, Beidou, Galileo, QZSS |
| NFC* |
Yes |
| Infrared port |
Yes |
Network
| Number of SIM* |
2 |
| Type of SIM card |
Nano |
| Multi SIM mode |
Standby |
| eSIM support* |
No |
| Hybrid slot |
No |
| LTE Cat* |
20 |
| 2G network |
GSM 850/900/1800MHz |
| 3G network |
WCDMA 1/4/5/8 |
| 4G network |
LTE 1/3/4/5/8/18/19/26/28A/34/38/39/40/41/66 |
| 5G support |
Yes |
| Speakers |
Stereo |
| Headphone audio jack |
No |
| FM radio |
No |
| Dolby Atmos |
Yes |
| Category |
Flagship |
| Announced |
June 2024 |
| Release date |
June 2024 |
| Launch price (MSRP) |
$700 |
| Successor |
- OnePlus Ace 5 Ultra |
| Sensors |
- Proximity sensor
- Gyroscope
- Accelerometer
- Ambient light sensor
- Compass
- Fingerprint |
| Bundled charger |
Yes, 100 W |
*Disclaimer! Some specifications of the Ace 3 Pro may differ by country or region
